Product Features
1. Stylish Design
Stylish appearance, smooth operation
IP54 rating, smooth curved fiberglass blades
Multiple color options
2. Flexible Usage
Wide range of power and voltage options
Can be used in combination with solar panels
3. Reliable Performance
High efficiency at low wind speeds (2.5 m/s)
Suitable for all scenarios
Long service life of up to 20 years, quality guaranteed
ISO certified
4. Advanced Technology
Sustainable energy production
Contributing to global environmental protection
Core-less PMG low-speed design
| Model | JV-600W | JV-1000W | JV-1500W | JV-2000W | JV-3000W |
| Rated power | 600W | 1000W | 1500W | 2000W | 3000W |
| Max Power(w) | 610W | 1080W | 1580W | 2100W | 3200W |
| Rated voltage | 12V/24V | 12V/24V | 24V/48V | 24V-96V | 48V/96 |
| Start-up wind speed | 2m/s | 2m/s | 2m/s | 2.5m/s | 2.5m/s |
| Rated wind speed | 11m/s | 11m/s | 12m/s | 12.5m/s | 12.5m/s |
| Wheel diameter | 0.5m | 0.5m | 0.6m | 0.8m | 0.8m |
| Generator type | Three-phase AC permanent magnet generator/permanent magnet suspension generator | ||||
| Number of blades | 2 | ||||
| Safety wind speed | 35m/s | ||||
| Braking method | Electromagnetic brake | ||||
| Blade material | Aluminum alloy | ||||
| Working temperature | -30℃～70℃ | ||||
| Insulation class | F | ||||
| Protection class | IP54 | ||||
| Lifespan | 20 Years | ||||
